Image Sensor
|
1/2.7" Progressive Scan CMOS
|
Min. Illumination
|
Color: 0.028 Lux @ (F2.0, AGC ON)
B&W: 0.0028 Lux @ (F2.0, AGC ON), 0 Lux with IR
|
Day & Night
|
IR Cut Filter
|
WDR
|
120 dB
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
|
Field of Vision
|
1.68 mm 180° (H), 101°(V), 180° (D)
|
IR Distance
|
Up to 10 m
|
Video Compression
|
H.265+/H.264+/H.265/H.264
|
Max. Resolution
|
2688 × 1520
|
Max. Frame
|
50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 24fps (2688 × 1520), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
|
Power
|
12 VDC, 0.48 A, max. 5.8 W; PoE (802.3af, 36 V to 57 V), 0.19 A to 0.12 A, max. 6.8W
|
Working Temperature
|
-10 °C to 40 °C (14 °F to 104 °F), humidity 95% or less (non-condensing)
|
Material
|
Metal & Plastic
|
Dimensions
|
Φ 127.3 × 104.1 mm (Φ 5" × 4.1")
|
Weight
|
Approx. 520 g (1.1 lb.)
|
