Barrier gates with straight boom pole | DS-TMG520-M(4m octagonal)

Name: Barrier gates with straight boom pole | DS-TMG520-M(4m octagonal)
Brand: Viskou – Connecting Intelligence, Powering The Future
SKU: 315101978
Price: 5160.4 SGD
Availability: InStock

DS-TMG520-M(4m octagonal)

- Adjustable Speed, Fast Open / Slow Close
- Multi Safety Protection (IR / Loop / Sensor)
- Heavy-duty Housing, IP54 Protection
- Multiple Control Modes (Remote / System)
- Vehicle Detection & Anti-collision

S$5,160.40 ~~S$10,689.40~~

(Excluding GST)

Add to Favorite Items

Description

DS-TMG520-M(4m octagonal)
Barrier gates with straight boom pole

Product Specifications

Matched Boom Pole Type	Round boom pole: 1 to 4 m anti-collision Octagonal boom pole: 1 to 6 m Octagonal telescopic boom pole: 4 to 6 m Boom pole ≥ 5 m: with spindle rod
Rising/Falling Speed	Raising: 1.5S(Default) Adjustable 1.5S, 2S, 2.5S Falling: 3.5S(Default) Adjustable 2.5S, 3S, 3.5S
Number of Cycles	5000000
Motor Type	DC brushless motor
Working Voltage	220 VAC ± 15%
Current	1.5 A
Consumption	300W
Working Temperature	-30 °C to 70 °C (-22 °F to 158 °F)
Barrier Housing Dimensions (L × W × H)	1248 × 486 × 480 mm (49.1 × 19.1 × 18.9 inch)
Body Weight	59.3 ± 5 kg (130.7 ± 11.0 lb.)
