Technical
specifications
|
Dimensions (H x W x D)
|
270 mm x 196 mm x 51 mm
|
Weight
|
1.14 kg
|
Port
|
1 x 2.5GE (RJ45) port, 100M/1000M/2500M auto-sensing
Note: The 2.5GE electrical port supports PoE IN.
|
LED indicator
|
Indicate the power-on, startup, running, alarm, and fault states of the system.
|
Power
specifications
|
Power input
|
PoE power supply: in compliance with IEEE 802.3at/af
Note:When working in IEEE 802.3af power supply mode, the AP is restricted in
functions. For details, see the Quick Information Check website.
|
Maximum power
consumption
|
18.8 W
Note: The actual maximum power consumption depends on local laws and
regulations.
|
Environmental
specifications
|
Operating temperature
|
–30°C to +60°C (From 1800 m to 5000 m, the maximum temperature
of the device decreases by 1°C for every 300 m increase in altitude.)
Note:The temperature on part of the AP shell may be higher than its operating
temperature upper limit. The AP's performance will not be affected as long
as the shell temperature complies with the safety standards.
|
Environment
specifications
|
Storage temperature
|
–40°C to +70°C
|
Operating humidity
|
5% to 95%
|
IP rating
|
IP65
|
Altitude
|
–60 m to +5000 m
|
Atmospheric pressure
|
53 kPa to 106 kPa
|
Radio
specifications
|
Antenna type
|
Built-in omnidirectional antennas
|
Antenna gain
|
2.4 GHz: 4 dBi
5 GHz: 7 dBi
Note:
1. The preceding gain is the peak gain of a single antenna.
2. Equivalent antenna gain after all 2.4 GHz or 5 GHz antennas are
combined: 2 dBi for 2.4 GHz and 4 dBi for 5 GHz.
|
Maximum quantity of
SSIDs on each radio
|
10
|
Maximum number of
access users
|
≤ 256
Note:The actual number of users varies according to the environment.
|
Maximum transmit power
|
2.4 GHz: 28 dBm (combined power)
5 GHz: 27 dBm (combined power)
Note:The actual transmit power varies according to local laws and regulations.
|
Power adjustment
Increment
|
1 dBm
|
