Image Sensor
|
1/2.9 " Progressive Scan CMOS
|
Min. Illumination
|
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
|
Wide Dynamic Range
|
Digital WDR
|
Angle Adjustment
|
Pan: 0° to 355°, tilt: 0° to 70°, rotate: 0° to 355°
|
Focal Length & FOV
|
2.8 to 12 mm, horizontal FOV 102.4° to 31.2°, vertical FOV 54.4° to 17.5°, diagonal FOV 121.8° to 35.7°
|
DORI
|
D: 45.7 to 141.4 m, O: 18.1 to 56.1 m, R: 9.1 to 28.3 m, I: 4.6 to 14.1 m
|
Lens Mount
|
Ø 14
|
Max. Resolution
|
1920 x 1080
|
Camera Material
|
Metal & Plastic
|
Camera Dimension
|
Ø 121.5 mm × 97.6 mm (Ø 4.78" × 3.84")
|
Camera Weight
|
Approx. 540 g (1.2 lb.)
|
Power Interface
|
Ø 5.5 mm coaxial power plug
|
Protection
|
IP67: IEC 60529-2013, IK08: IEC 62262:2002
|
