Model |
LRS-200-5 |
LRS-200-12 |
LRS-200-15 |
LRS-200-24 |
LRS-200-36 |
LRS-200-48 |
|
output |
DC voltage |
5V |
12V |
15V |
24V |
36V |
48V |
Rated current |
40A |
17A |
14A |
8.8A |
5.9A |
4.4A |
|
Current range |
0~40A |
0~17A |
0~14A |
0~8.8A |
0~5.9A |
0~4.4A |
|
Rated power |
200W |
204W |
210W |
211.2W |
212.4W |
211.2W |
|
Ripple&noise |
150mVp-p |
150mVp-p |
150mVp-p |
150mVp-p |
200mVp-p |
200mVp-p |
|
DC voltage ADJ. range |
±10% |
±10% |
±10% |
±10% |
±10% |
±10% |
|
Voltage toleranceNote.3 |
±3% |
±2% |
±1% |
±1% |
±1% |
±1% |
|
Line regulationNote.4 |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
Load regulationNote.5 |
±2% |
±1% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
Setup,rise,hold up time |
800ms,50ms,16ms/230VAC(full load) |
||||||
input |
Voltage range |
90~132VAC/180~264VAC(selected by switch),240~373VDC |
|||||
Frequency range |
47~63HZ |
||||||
AC current |
4.0A/115VAC 2.2A/230VAC |
||||||
Inrush current |
Cold start 50A/230VAC |
||||||
Efficiency |
85% |
87% |
88% |
89% |
89% |
90% |
|
Leakage current |
<2mA/240VAC |
||||||
protection |
overload |
Rated output power110%~140% start over load protection |
|||||
protection type:hiccup mode,auto-recovery after fault condition is removed |
|||||||
Over voltage |
Rated output voltage 115%~135% Start over voltage protection |
||||||
Protection type:hiccup mode,auto-recovery after fault condition is removed |
|||||||
Over temperature |
100℃±10℃(RTH3 detect beside magnetic core) |
||||||
Protection type:cut off the output,auto-recovery after the temperature become normal |
|||||||
environment |
Working temp,humidity |
-25℃~+70℃(Please refer to“derating curve”) |
|||||
Storage temp,humidity |
-40℃~+85℃,10%~95%RH non-condensing |
||||||
Withstand vibration |
10~500HZ,2G10min/1cycle,period for 60 minutes,each axes |
||||||
safety |
Withstand voltage |
I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:1.25KVAC |
|||||
Isolation resistance |
I/P-O/P,I/P-FG,O/P-FG:100Mohms/500VDC |
||||||
Fit standard |
Safety standards |
Compliance to UL60950-1,TUV EN60950-1,GB4943 |
|||||
EMC emission |
Compliance to EN55032(CISPR22)Class A,GB9254 Class B,EN55014,EN61000-3-2,3 |
||||||
EMC immunity |
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024,EN61000-6-1 |
||||||
others |
Dimension |
215*115*30mm(L*W*H) |
|||||
Weight/packing |
0.66kg/20pcs/14.2kg/0.024m³/0.85CUFT |
||||||
MTBF |
≥320K hrs min. MIL-HDBK-217F(25℃) |
