16-ch 5 MP 1U H.265 AcuSense DVR | iDS-7216HUHI-M2/S

Name: 16-ch 5 MP 1U H.265 AcuSense DVR | iDS-7216HUHI-M2/S
Brand: Viskou E-Shop
SKU: 300227700
Price: 808 SGD
Availability: InStock

iDS-7216HUHI-M2/S

- Deep learning-based motion detection 2.0 for all analog channels
- H.265 pro+ compression technology
- Encoding ability up to 8 MP @ 8 fps, 5 MP @ 12 fps
- 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
- Up to 32 network cameras

S$808.00 ~~S$1,469.00~~

(Excluding GST)

Quantity

3 In Stock, Ubi

4 In Stock, Bukit batok

12 In Stock, Tuas

Add to Favorite Items

Description

iDS-7216HUHI-M2/S
6-ch 5 MP 1U H.265 AcuSense DVR

Compression and Recording

H.265 Pro+ video compression improves encoding efficiency, and reduces data storage costs
Recording at up to 8 MP resolution

Storage and Playback

2 SATA interfaces
Smart search for efficient playback
Support the third party cloud storage

Smart Function

Deep learning-based motion detection, and perimeter protection (line crossing and intrusion detection)
Support multiple VCA (Video Content Analytics) events for both analog and smart IP cameras

Network & Ethernet Access

Compatible with major Wi-Fi dongle products in the market
Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
Output bandwidth limit configurable

Product Specifications

Human/Vehicle Analysis	Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
Perimeter Protection Human/Vehicle Analysis	Up to 4-ch
Video compression	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution	Main stream: 8 MP@8 fps/5 MP@12 fps/3K@12 fps/4 MP@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)
IP video input	8-ch (up to 24-ch) Enhanced IP mode on: 16-ch (up to 32-ch), each up to 4 Mbps Up to 8 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input	16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI input	8 MP@15 fps, 5 MP@20 fps, 3K@20 fps, 4 MP@30 fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps
AHD input	5 MP@20 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
HDCVI input	4 MP@30 fps, 4 MP@25 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
VGA output	1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output
HDMI output	1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
Audio input	1-ch (up to 16-ch is optional), RCA (2.0 Vpp, 1 KΩ)
Synchronous playback	16-ch
Wi-Fi	Connectable to Wi-Fi network by Wi-Fi dongle through USB interface
Capacity	Up to 10 TB capacity for each disk
Dimension (W × D × H	380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)
Weight (without HDD)	≤ 2.1 kg (4.6 lb)

Datasheet

Download Datasheet

Customer Reviews

Write a review

Sign In With:

16-ch 5 MP 1U H.265 AcuSense DVR | iDS-7216HUHI-M2/S

Quantity

Human/Vehicle Analysis

Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;

Perimeter Protection Human/Vehicle Analysis

Up to 4-ch

Video compression

H.265 Pro+/H.265 Pro/H.265/H.264+/H.264

Encoding resolution

Main stream: 8 MP@8 fps/5 MP@12 fps/3K@12 fps/4 MP@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)

IP video input

8-ch (up to 24-ch) Enhanced IP mode on: 16-ch (up to 32-ch), each up to 4 Mbps Up to 8 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras

Analog video input

16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDTVI input

8 MP@15 fps, 5 MP@20 fps, 3K@20 fps, 4 MP@30 fps, 4 MP@25 fps, 3 MP@18 fps, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps

AHD input

5 MP@20 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps

HDCVI input

4 MP@30 fps, 4 MP@25 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps

VGA output

1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz HDMI/VGA simultaneous output

HDMI output

1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output

Audio input

1-ch (up to 16-ch is optional), RCA (2.0 Vpp, 1 KΩ)

Synchronous playback

16-ch

Wi-Fi

Connectable to Wi-Fi network by Wi-Fi dongle through USB interface

Capacity

Up to 10 TB capacity for each disk

Dimension (W × D × H

380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)

Weight (without HDD)

≤ 2.1 kg (4.6 lb)
